BCM

BCM • A gantry style 5-axis machining center with moving column and crossrail. Combines fast linear guideways on XY and rigid box ways on Zand W Heavy duty work table supports 1,000 lb/sq. ft.

Performance Specifications
Model	xx38	xx43	xx48	xx53
X-Travel	244~1425
Y-Travel	150	169	189	209
Z-Travel	39 (47/59)*
W-Travel	39 (47/59)*
Nose Taper	BT-50
Speed (rpm)	6,000
Feed Rate (ipm)	472 / 472 / 472 / 78
Motor** (hp)	29 135 (40 / 50)*
Unit= inch  |  *Optional accessory   |  **30 minute rating

EFFICIENT 5-AXIS MACHINING

Moving Column and Moving Crossrail

The BCM gantry machining center has a W-axis that allows the crossrail to move vertically over a range of 59˝ (1.5M). Progressive hydraulic clamping ensures accurate W-axis movement during cutting. Nose to table distance has up to 10 feet of clearance under the spindle.

Perform five-face machining with an angular head or 5-axis machining with a 2-axis contouring head. Smooth axial movement along hardened and rigid box ways on both the W-axis and Z-axis.

PERFORMANCE FEATURES

• Rigid tapping
• X/Y/Z absolute encoder
• Table sizes up to 1417˝ (L) × 138˝ (W)
