JHD 1503-3205
Dual Spindle
JHD • Double spindle grinding machine-uses a 3-jaw chuck coupled with an OD wheel spindle and ID wheel spindle. The two spindles can grind two different surfaces simultaneously or two different pieces at the same time. Ideal for precision grinding and polishing of small and medium-sized workpieces.
Performance Specifications | ||
|---|---|---|
| Machine Model | 1503 | 3205 |
| ID Hole Depth | 0.25~8×6 | 0.25~5×3 |
| Grinding Diameter Max. | 5.9 | 12.5 |
| Grinding Length Max. (OD & ID) | 4/5 | 8/4 |
| Swing Over Bed Max. | 12 | 20 |
| Workpiece Weight Max. (lb) | 220 | 287 |
| Chuck Size | 6 | 8 |
| Unit= inch | *Optional accessory | **30 minute rating | ||
Available Models: 1503, 3205
