VMC 1688
3-Axis
VMC-1688 • Four slide ways under the Y-axis saddle provide heavy loading capacity. Utilizes a box structure body casting that yields high rigidity. And a one-piece casting ensures no leakage and excellent chip removal.
Performance Specifications | |
|---|---|
| X-Travel | 53 |
| Y-Travel | 35 |
| Z-Travel | 28 / 35* |
| Nose Taper | #50 |
| Speed (Gear) rpm | 8000 |
| Speed DDS* (rpm) | 10,000 |
| Drive Motor** (hp) | 20/25 |
| CNC Control | Fanuc |
| Unit= inch | *Optional accessory | **30 minute rating | |
Available Models: 1688
