MH-5TR
3-Axis+AB
MH-5TR • Horizontal spindle coupled with A-axis trunnion table and a 8-axis rotary table performs precision machining for complex horizontal parts applications.
Performance Specifications | |
|---|---|
| X-Travel | 35~67 |
| Y-Travel | 35~65 |
| Z-Travel | 47~65 |
| A-Travel | ±120° /-30° ~ +120° |
| B-Travel | ±360° |
| Table Diameter | Φ25~Φ51 |
| Nose Taper | #50 |
| Speed (Gear) rpm | 6000 |
| Speed (DDS) rpm | 8000 |
| Drive Motor** (hp) | 25/30/47 |
| CNC Control | Fanuc I Siemens |
| Unit= inch | *Optional accessory | **30 minute rating | |
Available Models: 630, 800, 1100, 1300
