VTL-MDS 2500-4000
2-Axis
VTL -2500MDS and VTL -4000MDS Designed for large parts vertical turning with an optional milling function. Features a W-axis with dual columns, and dual ballscrews. And two spindle motors to power the work table.
Performance Specifications | ||
|---|---|---|
| Machine Model | 2500MDS | 4000MDS |
| Table Diameter | 78 | 118 |
| Turning Diameter Max. | 96 | 157 |
| Swing Max. | 98 | 157 |
| Table Load Max. (lb) | 44,000 | 66,000 |
| X-Travel | 70 | 161 |
| Z-Travel | 39 | 59 |
| Table Speed 2-step (rpm) | 200 | 80 |
| W-Axis Crossrail Stroke | 32 | 59 |
| Crossrail Levels | – | 9.8 x 7 levels |
| Main Table Motor** (hp) | 50 x 2 | 60 x 2 |
| ATC Tools | 18 | 18 |
| Unit= inch | *Optional accessory | **30 minute rating | ||
Available Models: 2500, 4000
